Application Purpose

Characteristics

Ordering information

Product Details

●Conceal installation , for squatting WC .

● Adjustable flush volume .

●Left  side water  connection  .

●Cistern heat preservation,anti-condensation protection .

● 1/2” x 3/8”Water supply angle valve

● 1/2”x1/2”water supply connect  valve .

●Flush connect pipe , Ф45,standard length 180mm , can order 250mmlength .

● Flush connect pipe rubber ,match the Ф55mm or Ф42mm ceramic flush hole .

● Maintain window protect frame , ABS material，can be cut according to the actually height .

● Protection plug .

● 4 hole on the iron sheet for fasten on the wall .

● 4group setscrew .

●Maximum flush can adjustable between 6L/7.5L .

●Maximum flush can adjustable between 3L/4L .

● Factory flush setting 3L/6L
